What's included in the sign site plan?



The purpose of a signage site plan is to deliver a precise and detailed representation of the signange and property to support sign installation and business needs. Every aspect of the property relevant to signage placement should be included to ensure accuracy and compliance. Typical elements featured in these plans include:



✔ Property Lines

✔ Primary Structure Roofline

✔ Lot Dimensions

✔ North Arrow

✔ Scale

✔ Measurements between features

✔ Paths



Overview


A high-detail signage site plan designed for businesses to meet commercial permitting requirements. We draft precise signage site plans, including necessary existing features for the project

(such as buildings, parking areas, landscaping), via

GIS (Geographical Information System), satellite imagery,

zoning maps and client provided information to create the first draft which is sent to the client to verify dimensions. We make no representation regarding the accuracy of our sources.



After completing the draft, we’ll send it to you for review. If adjustments are required—such as refining dimensions or adding missing elements—you can provide feedback, and we’ll revise the plan at no additional cost. This process guarantees a detailed, accurate plan to support your signage and permitting goals.



*The site plans provided by our company are not certified and are not intended to serve as legal surveys. It is the client’s responsibility to ensure that all survey-related information, including photos, sketches, dimensions, and notes, is accurate. Our company cannot be held responsible for permit denials caused by inaccurate or incomplete client-provided information. As long as a non-certified plan is acceptable for your project, we stand by our work.


Sign Site Service Package
Our sign site service package delivers meticulously crafted site plans with precise scaling and detailed elevation drawings, ensuring accuracy for every project.

$189 plus tax. $69 each additional sign.
